AM-480 Antenna Specifications
| Frequency Range | 1.0 – 18.0 GHz |
| VSWR | 2.5:1 nom |
| Gain | +1.0 dBli nom |
| Gain Tracking | ±1.0 dB on axis |
| Beam width (3 dB) | 75° ±15° typ |
| Polarization | Circular, LHCP or RHCP available |
| Axial Ratio Boresight | ≤2.0 dB |
| Power Handling | 1 watt CW |
| Connector | SMA female in line with boresight |
| Weight | 5 lb 2 oz. |
| Finish | Exterior of antenna made from No. 316 stainless steel, except for radome, connector and hardware |
| Option: | LHCP or RHCP available |
